Deadlift Narrow Rail 35"

50,000 lbs. Hoist Capacity

8" Main Frame - 28' length - 17,280 lbs

72.5k GVW Outer Bridge

22’-26’ Can Size

Trailer Frame 36 lb. W.F. (250 - 16", 330/366 - 19.5") I- Beam A36 Steel & C-Channel Cross Members

Hoist Main Frame 8" X 4" X 1/2" - 10" X 4" X 1/2" on 330 and up models

Full Length Tractor Fenders

Contoured Poly Tandem Fenders w/ Brackets for Axle Spread Range of 52"-53"

10-Hole Hub Piloted Steel Rims w/ 11R/22.5 Tires - 16 Ply & Wheel Check Indicators

2-Spool Control Valve

50,000 lb.  Hutch Single Point Suspension w/ (2) - 25,000 lb. Axles

Total Trailer GVWR Rated between 72.5k - 75k lbs., 50k-60k lb. Hoist Capacity Rating - 18" Kingpin Set

Flip Up/Down Over the Cylinder Aux. Stops without Ramp

36” Steel Toolbox

Trailer Brake at Street Side Front

ABS Braking System

Brake control spring loaded

50k lb. Lift / 140k lb. Vertical Load Twin Leg Manual Landing Gear

(2) - 6" 3-stage Telescopic Lift Cylinders

Hoist Maintenance Props

(2) - 7" DA Single Stage Winch Cylinders

7/8" Cable w/ Cable End & Cable End Holder

10" Grease Grooved Sheaves

Automatic Front Container Spring Loaded Locking System

4" OD Outside Rail Rollers

Stationary Rear Hold-Downs

6" Rear Ground Roller (Deadlift Rear Roller Assy. On HH- model)

Mid-Body LED Turn Signals & ABS Brake Indicator Light on Driver's Side

DOT Approved LED Rear Lighting

Heavy Duty Casted Ductile Iron Rear Hinge w/ (2) - 2" Steel Pins

Seven Wire Electric Trailer Plug Connection

Five Wire Electric Pig Tail Connection

Turn Lock Quick Disconnects

1 1/4" Return Line w/ Quick Disconnect Threaded Male End

1" Pressure Line w/ Quick Disconnect Threaded Female End

Hot Phosphatized Wash then Primed & Painted w/ 2-Part Baked on Epoxy
